One-Way Throttle Valve 151162 Grla-M5-Pk-4-B Original Spot

GRLA-M5-PK-4-B

151162

Adjustment component: Slotted head screw

Technical Data

• Valve functionExhaust air one-way flow control function

• Pneumatic connection, port 1PK-4

• Pneumatic connection, port 2M5

• Adjustment componentSlotted head screw

• Type of mountingScrew-in

• Standard nominal flow rate in flow control direction83 l/min

• Standard nominal flow rate in blocked direction76 l/min ... 88 l/min

• Operating pressure0.2 bar ... 10 bar

• Ambient temperature-10 °C ... 60 °C

• Maritime classificationSee certificate

• Explosion protectionThe information in the certificate must be observed! Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX)

• Mounting positionoptional

• Symbol00991452

• Standard flow rate in flow control direction 0.6->0 MPa (6->0 bar, 87->0 psi)140 l/min

• Standard flow rate in non-return direction 0.6->0 MPa (6->0 bar, 87->0 psi)128 l/min ... 148 l/min

• Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4]

• Note on operating and pilot mediumLubricated operation possible (in which case lubricated operation will always be required)

• LABS (PWIS) conformityVDMA24364-B1/B2-L

• Cleanroom classClass 4 according to ISO 14644-1

• Media temperature-10 °C ... 60 °C

• Nominal size2 mm

• Max. tightening torque1.5 Nm

• Product weight10 g

• Material screwed plugNickel-plated

• Note on materialsRoHS-compliant

• Material sealsNBR

• Material adjusting screwBrass

• Material swivel fittingDie-cast zinc
